SEN A030 (x2)

Interior

Exterior

ULlistingUS Pending

Class III

RoHS

TM-30 Results

24V DC

60W/m

78lm/W

IP44 / IP67

50,000hrs

24V DC

18.29W/ft

78lm/W

IP44 / IP67

50,000hrs

Homogenous

Detalles de producto

Gran perfil lineal con tiras gemelas de potente LED A-line A030.
Opciones de cubierta de persiana totalmente difusa, transparente o micro persianas disponibles.
Varios accesorios de montaje en superficie disponibles.
Salida de hasta 4680 lúmenes por metro.
A-line CCT: 2700K, 3000K, 4000K.

Unidad: Métrica Imperial

Datos del producto

Lumen/m Lumen/ft

Lumen/W

Vida útil / horas

Cubierta clara

A-line

4680

1426

78

50,000

Cubierta difusa

A-line

3660

1116

61

50,000

Cubierta transparente + micro louvre

A-line

2400

732

40

50,000

Accesorios/Opciones

Descargas

KKCP-12 (SEN)

Lock clip
Allow 2 per metre
Stainless steel finish
L38/W40.3/H70mm

Lock clip
Allow 2 per 40"
Stainless steel finish
L1.50/W1.59/H2.76"

KKBK-02 (SEN)

Fixed bracket
Allow 2 per metre
Steel finish
L40/W39.2/H68.8mm

Fixed bracket
Allow 2 per 40"
Steel finish
L1.58/W1.54/H2.71"

KKBK-09 (SEN)

Mounting plate
Allow 2 per metre – factory fitted
Silver anodised aluminium finish
L50/W39.2/H52.3mm

Mounting plate
Allow 2 per 40" – factory fitted
Silver anodised aluminium finish
L1.97/W1.54/H2.06"

KKBK-16 (SEN)

Small adjustable bracket
Allow 2 per metre
Silver anodised aluminium finish
L46/W70/H79.1mm

Small adjustable bracket
Allow 2 per 40"
Silver anodised aluminium finish
L1.8/W2.76/H3.11"

KKBK-23 (SEN)

Low adjustable bracket
Allow 2 per metre
Silver anodised aluminium finish
L34/W39/H58.1mm

Low adjustable bracket
Allow 2 per 40"
Silver anodised aluminium finish
L1.34/W1.54/H2.29"

RC - Rear cable exit (SEN)

Not compatible with low profile bracket (KKBK-23) or mounting plate (KKBK-09)
H56.9mm

Not compatible with low profile bracket (KKBK-23) or mounting plate (KKBK-09)
H2.24"

SC - Side cable exit (SEN)

Required for use of low adjustable bracket (KKBK-23)
W56.4mm

Required for use of low adjustable bracket (KKBK-23)
W2.22"

KKBK-17 (SEN)

Large adjustable bracket
Allow 2 per metre
Silver anodised aluminium finish
L46/W70/H129.4mm

Large adjustable bracket
Allow 2 per 40"
Silver anodised aluminium finish
L1.8/W2.76/H5.09"

B - Clear Cover (SEN)

Clear cover

Clear cover

C - Diffused Cover (SEN)

Diffused cover

Diffused cover

K - Clear cover + micro louvre (SEN)

Clear cover + micro louvre

Clear cover + micro louvre

Spec SEN A030 (x2) Install SEN A030 (x2) CE Certificate SEN A030 (x2)

CAD SEN A030 (x2) BIM SEN A030 (x2) IES SEN A030 (x2) LDT SEN A030 (x2)
