DUO Luna

Accessories / Options    |    Downloads    |    Videos
Select LED:
White (Low output)
RGB

DUO Luna White

InteriorExteriors-linee-lineL70 B10>50000hULlistingUS 356145CELM79LM80
9V DC / 12V DC
5.3W/m / 3.7W/m
≤87.6lm/W
IP40 / IP65 / IP68
50,000hrs
9V DC / 12V DC
1.6W/ft / 1.13W/ft
≤87.6lm/W
IP40 / IP65 / IP68
50,000hrs
Product Details
  • A versatile, cost effective, flexible light source for backlighting and concealed illumination
  • Polycarbonate casings, hardwired with a choice of 9 or 13 modules per metre (320 or 459lm per metre)
  • Available with a full range of white colour temperatures (>90 CRI) and in single colours or RGB
  • IP68 version with resin encapsulation and ultrasonic case welding for superior protection
  • CCT: 2100K, 2300K, 2500K, 2700K, 3000K, 3200K, 3500K, 4000K, 5000K
  • Colour: Red, Green, Blue, Orange, Amber
  • RGB
Unit: Metric Imperial
Product Data
Lumen/mLumen/ft
Lumen/W
Lifetime/hrs
Clear cover (9v DC 13 modules)
s-line
460
140
87.1
50,000
e-line
460
140
87.1
50,000
Clear cover (9v DC 9 modules)
s-line
320
98
87.6
50,000
e-line
320
98
87.6
50,000
Clear cover (12v DC 13 modules)
s-line
460
140
65.4
50,000
e-line
460
140
65.4
50,000
Clear cover (12v DC 9 modules)
s-line
320
98
64.8
50,000
e-line
320
98
64.8
50,000
All data based on 3000K

Downloads

Installation Guide
