MOMO-R
Accessories / Options
|
Downloads |
Videos
MOMO-R Projects
Select LED:
Unit:
Metric
Imperial
New
R007
7W/m
2.13W/ft
≤563lm/m (81lm/W)
≤172lm/ft (81lm/W)
New
R014
14W/m
4.27W/ft
≤1152lm/m (82lm/W)
≤351lm/ft (82lm/W)
New
R020
20W/m
6.10W/ft
≤1632lm/m (82lm/W)
≤498lm/ft (82lm/W)
New
R030
30W/m
9.14W/ft
≤2309lm/m (77lm/W)
≤704lm/ft (77lm/W)
New
A040
40W/m
2.13W/ft
≤3668lm/m (92lm/W)
≤1118lm/ft (92lm/W)
New
R207
16W/m
4.88W/ft
Variable white
Variable white
New
RGBW
20W/m
6.10W/ft
Dynamic colour change
Dynamic colour change
New
RGB
15.6W/m
4.75W/ft
Colour change
Colour change
MOMO-R R030
24V DC
30W/m
≤77lm/W
IP44 / IP67
50,000hrs
24V DC
9.14W/ft
≤77lm/W
IP44 / IP67
50,000hrs
Homogenous
New
Product Details
Recessed compact profile with wide range of LED strip types suitable for interior or exterior use.
Clear or diffused covers with wide range of lens and louvre options available.
Recessed mounting via spring clips.
IP44 or IP67 ratings available.
Output up to 3668 lumens per metre.
s-line / k-line CCT: 1900K, 2100K, 2300K, 2500K, 2700K, 3000K, 3500K, 4000K, 5000K.
A-line CCT: 2700K, 3000K, 4000K.
LEDmix dynamic white.
RGBW.
RGB.
Unit:
Metric
Imperial
Product Data
Lumen
/m
Lumen
/ft
Lumen
/W
Lifetime
/hrs
Asymmetric lens
s-line
2306
703
77
50,000
k-line
2175
663
73
50,000
Clear cover
s-line
2309
704
77
50,000
k-line
2178
664
73
50,000
Diffused cover
s-line
1040
317
35
50,000
k-line
981
299
33
50,000
Micro louvre + clear
s-line
687
209
23
50,000
k-line
648
198
22
50,000
KKLN-01 18° + clear cover
s-line
1285
392
43
50,000
k-line
1212
369
40
50,000
KKLN-01 18° + micro louvre
+ clear cover
s-line
572
174
19
50,000
k-line
540
165
18
50,000
Clear Cover + KKLN-03 23°
s-line
1332
406
44
50,000
k-line
1257
383
42
50,000
Clear Cover + KKLN-03 23° + Micro Louvre
s-line
760
232
25
50,000
k-line
717
219
24
50,000
All data based on 3000K
Accessories / Options
Downloads
KKCR-01 Cable Raceway (MOMO-R)
KKCR-01-1000 1000mm
KKCR-01-2000 2000mm
KKCR-01-3000 3000mm
Cable raceway (Cut & drilled to fit on site)
Anodised aluminium finish
W22/H36.4mm
KKCR-01-1000 39.37in
KKCR-01-2000 78.74in
KKCR-01-3000 118.11in
Cable raceway (Cut & drilled to fit on site)
Anodised aluminium finish
W0.87/H1.43"
KKSB-01 (MOMO-R)
Spring bracket
Allow 2 per metre
Anodised aluminium finish
L31/W35.4/H45.2mm
Spring bracket
Allow 2 per 40"
Anodised aluminium finish
L1.22/W1.39/H1.78''
A - Clear Cover + KKLN-03 (MOMO-R)
Not compatible with RGBW
Clear Cover
23º beam angle lens (KKLN-03)
Not compatible with RGBW
Clear Cover
23º beam angle lens (KKLN-03)
AK - Clear Cover + KKLN-03 + Micro louvre (MOMO-R)
Not compatible with RGBW
Clear Cover
23º beam angle lens (KKLN-03)
Micro louvre
Not compatible with RGBW
Clear Cover
23º beam angle lens (KKLN-03)
Micro louvre
B - Clear Cover (MOMO-R)
Clear PC Cover
Clear PC Cover
BA2 - Clear Cover + KKLN-A2 (MOMO-R)
Not compatible with RGB, RGBW
Clear Cover
Asymmetric lens (KKLN-A2)
Not compatible with RGB, RGBW
Clear Cover
Asymmetric lens (KKLN-A2)
C - Diffused Cover (MOMO-R)
Diffused PC cover
Diffused PC cover
K - Clear Cover + Micro louvre (MOMO-R)
Clear Cover
Micro louvre
P - Clear Cover + 14° KKLN-01 (MOMO-R)
Not compatible with A040, RGBW
Clear PC Cover
14° beam angle lens
Not compatible with A040, RGBW
Clear PC Cover
14° beam angle lens
U - Clear Cover + KKLN-01 + Micro louvre (MOMO-R)
Not compatible with A040, RGBW
Clear Cover
14º beam angle lens (KKLN-01)
Micro louvre
Not compatible with A040, RGBW
Clear Cover
14º beam angle lens (KKLN-01)
Micro louvre
Previous
Next
Spec MOMO-R R030
Install MOMO-R R030
CE Certificate MOMO-R R030
CAD MOMO-R R030
BIM MOMO-R R030
IES MOMO-R R030
LDT MOMO-R R030
Batch Download (.ZIP file)
Installation Guide
MOMO-R Family Videos
No videos to display
MOMO-R R030 Videos
No videos to display
