TIMI Glow

Accessories / Options    |    Downloads    |    Videos
TIMI Glow Projects

Select LED:

Unit: Metric Imperial
R014
14W/m4.27W/ft
≤697lm/m (50lm/W)≤213lm/ft (50lm/W)
Homogeneouss-linek-line
R020
20W/m6.09W/ft
≤912lm/m (46lm/W)≤278lm/ft (46lm/W)
Homogeneouss-linek-line
A010
10W/m3.05W/ft
≤700lm/m (70lm/W) ≤213lm/ft (70lm/W)
HomogeneousA-line
A020
20W/m6.10W/ft
≤1400lm/m (70lm/W)≤427lm/ft (70lm/W)
HomogeneousA-line

TIMI Glow A020

InteriorHomogeneousA-lineL70 B10>50000hULlistingUS PendingCEClass IIIRoHSLM79LM80TM-30 Results
24V DC
20W/m
70lm/W
IP40
50,000
24V DC
6.10W/ft
70lm/W
IP40
50,000
Homogenous
Product Details
  • Fully homogenous mini LED profile.
  • Innovative glowing end caps to minimise end-to-end shadowing, with dual cable exit design.
  • Snap in diffused cover with no visible spotting.
  • 3M tape or clip mounting methods.
  • Output up to 1400 lumens max per metre.
  • s-line / k-line CCT: 1900K, 2100K, 2300K, 2500K, 2700K, 3000K, 3500K, 4000K, 5000K.
  • A-line CCT: 2700K, 3000K, 4000K.
Unit: Metric Imperial
Product Data
Lumen/m Lumen/ft
Lumen/W
Lifetime/hrs
Diffused cover
A-line
1400
427
70
50,000

Accessories / Options

Downloads

Installation Guide

TIMI Glow Family Videos

TIMI Glow A020 Videos
