MOMO-L

Accessori/Opzioni | Downloads |

MOMO-L Progetti

Seleziona LED:

Unità: Sistema metrico Sistema imperiale

R007

7W/m2.13W/ft
Output Basso

R014

14W/m4.27W/ft
Output Medio

R020

20W/m6.10W/ft
Output Medio

R030

30W/m9.14W/ft
Output Massimo

A040

40W/m12.19W/ft
≤3640lm/m (91lm/W)≤1109lm/ft (91lm/W)

R207

16W/m4.88W/ft
Output dimanica media

RGBW

20W/m6.10W/ft
Output dimanica media

RGB

15.6W/m4.75W/ft
Colour changeColour change

MOMO-L A040

Interni

Esterni

ULlistingUS Pending

Class III

RoHS

TM-30 Results

IK10 tested

24V DC

40W/m

91lm/W

IP44 / IP67

50,000hrs

24V DC

12.19W/ft

91lm/W

IP44 / IP67

50,000hrs

Homogenous

New

Dettagli sul Prodotto

Profilo versatile e compatto con un'ampia gamma di tipi di strisce LED adatte per uso interno o esterno.
Coperture trasparenti o diffuse con ampia gamma di lenti e griglie disponibili.
Montaggio superficiale tramite clip o staffe nascoste.
Classificazione IP44 o IP67 disponibile.
Potenza fino a 3640 lumen al metro.
s-line / k-line CCT: 1900K, 2100K, 2300K, 2500K, 2700K, 3000K, 3500K, 4000K, 5000K.
A-line CCT: 2700K, 3000K, 4000K.
LEDmix dynamic white.
RGBW.
RGB.

Unità: Sistema metrico Sistema imperiale

Dati del Prodotto

Lumen/m Lumen/ft

Lumen/W

Ore di vita/hrs

Asymmetric lens

A-line

3640

1109

91

50,000

Clear cover

A-line

3640

1109

91

50,000

Diffused cover

A-line

1632

497

41

50,000

Clear cover + micro louvre

A-line

1840

561

46

50,000

Clear Cover + KKLN-03 23°

A-line

2064

629

52

50,000

Clear Cover + KKLN-03 23° + Micro Louvre

A-line

1152

351

29

50,000

Accessori/Opzioni

Downloads

KKBK-07 (MOMO-L)

Fixing plate
Consigliate 2 per metro
Finitura in alluminio anodizzato
L50/W25/H38mm

Fixing plate
Consigliate 2 per 40"
Finitura in alluminio anodizzato
L1.97/W0.98/H1.5"

KKBK-21 (MOMO-L)

Adjustable bracket
Consigliate 2 per metro
Finitura in alluminio anodizzato
L34/W25/H41.9mm

Adjustable bracket
Consigliate 2 per 40"
Finitura in alluminio anodizzato
L1.34/W0.98/H1.65"

KKCP-03 (MOMO-L)

Clip
Consigliate 3 per metro
Finitura in acciaio inossidabile
L25/W33.1/H33.5mm

Clip
Consigliate 3 per 40"
Finitura in acciaio inossidabile
L0.98/W1.3/H1.32"

KKCP-17 (MOMO-L)

Lock Clip
Consigliate 2 per metro
Finitura in acciaio inossidabile
L25/W26.1/H45mm

Lock Clip
Consigliate 2 per 40"
Finitura in acciaio inossidabile
L0.98/W1.03/H1.77"

A - Clear Cover + KKLN-03 lens (MOMO-L)

Not compatible with R207, RGBW
Clear Cover
KKLN-03 23° beam angle lens

Not compatible with R207, RGBW
Clear Cover
KKLN-03 23° beam angle lens

AK - Clear Cover + KKLN-03 lens + Micro Louvre (MOMO-L)

Not compatible with R207, RGBW
Clear Cover
KKLN-03 23° beam angle lens

BA2 - Clear Cover + KKLN-A2 Asymmetric lens (MOMO-L)

Not compatible with R207, RGB, RGBW
Clear Cover
KKLN-A2 Asymmetric lens

Not compatible with R207, RGB, RGBW
Clear Cover
KKLN-A2 Asymmetric lens

B - Clear Cover (MOMO-L)

Cover trasparente per PC

Cover trasparente per PC

C - Diffused Cover (MOMO-L)

Copertura diffusa
Finitura in policarbonato

Copertura diffusa
Finitura in policarbonato

K - Clear Cover + Micro Louvre (MOMO-L)

Clear PC cover
Micro Louvre (diffused internal cover)

P - Clear Cover + KKLN-01 (MOMO-L)

Not compatible with A040, R207, RGBW
Clear PVC cover
18° beam angle lens
Co-extruded PMMA

Not compatible with A040, R207, RGBW
Clear PVC cover
18° beam angle lens
Co-extruded PMMA

U - Clear Cover + Micro Louvre + KKLN-01 (MOMO-L)

Not compatible with A040, R207, RGBW
Clear PVC cover
18° beam angle lens
Co-extruded PMMA

Not compatible with A040, R207, RGBW
Clear PVC cover
18° beam angle lens
Co-extruded PMMA

Spec MOMO-L A040 Install MOMO-L A040 CE Certificate MOMO-L A040

CAD MOMO-L A040 BIM MOMO-L A040 IES MOMO-L A040 LDT MOMO-L A040

Download batch (file .ZIP)

MOMO-L Video di famiglia

Nessun video da visualizzare

MOMO-L A040 Video
